Horse Light Single (HL1) National level 3 Phase Competition Carriage. 14.2 to 16.2hh. From £2666

Horse Light Single (HL1). This carriage can be configured for 3 phase competition or Pleasure driving. Suit 14.2 to 16.2hh Weight Standard 220Kg. From £2666

Standard Details;

  • Carriage width: 125cm OR 138cm
  • Wheels: Pneumatic Knobbly or Road.
  • Spokes Straight or Curved, Painted.
  • Brakes: Rear wheel, stainless discs and parking valve. Pedal on RHS.
  • Shafts: Independent with T1 marathon eye tips, or T2,T3or T4. Painted. Shaft sizes IS3 or 4
  • Seats   Front PS1 Wedge and flat on side or PS5 Single wedge, or PS2 Flat Bench. Rear, RW Bench with fixed back support.
  • Upholstery: Eco leather gniot.
  • Suspension: SPR1 Three point spring system front and elliptical rear.

Options. For prices please see “OPTIONS” page under “Four Wheeler Options Prices”)

  • Wheels. Hard Rubber.
  • Spare Wheel Set, hard rubber tyres.
  • Spokes. Double straight, double banana, thin flat Model V or V45 . Model E 2//3 or F Flat wide
  • Stainless spokes.
  • Brakes: Front axle brakes
  • Parking brake MCB Mechanical crank.
  • Turntable Brake: Pedal in front or handle for groom.
  • Delayed Steering.
  • Shaft tips: TET telescoping with ertalon tip. Spokes in stainless or Galvanised.
  • Shafts: Stainless. Custom size
  • Front seat. PS3 2 Wedges in front. op8 Wedge with spring underneath, op5 Standard wedge moving to centre. op5 op8 Wedge with spring moving to centre.
  • Rear seat: Removable backs
  • Upholstery eco leather polonez
  • Suspension:AIRSPR1 Air suspension front and rear.

Accessories.

  • Stainless front (dash)
  • Stainless side pipe
  • Stainless groom’s handles
  • Stainless Bumpers
  • Stainless Steel seat frame for single wedge
  • Electric lighting
  • Carriage cover
  • Extendable rear axle
  • Additional seat for groom dickey seat
  • Custom shape of front dash
  • Sides of front of carriage in plate with rubber.
  • Special colour of upholstery
  • Leather Strap on groom handles
  • Suede seat surface on wedge
  • Decorative stitching on upholstery
  • Decorative trimming (piping) on upholstery
  • Number Holder
  • Foot-rail stainless pipe
  • Aluminium box under legs – for short people
  • Box under legs wooden – upholstered
  • Extension for back step for marathon
  • Door at the back of the carriage
  • Waterproof cover for docs
  • Speakers and multi-functional radio
  • Long cup for front wheels
  • Long cup for front stainless steel
  • Metallic or pearl paint
  • Panels stained natural wood
  • Box under front seat
  • Odometer
